Archive: Machinery and Equipment

Hail Isn’t Cool

Hail property damage is frequently reported after an HVAC service call.  Building owners are often unaware there is damage until the power bill starts trending higher and the HVAC system is simply not cooling effectively. Take look at the fins! The National Weather Service reported over $722 million in property damage from hail in 2018.  Based on NWS data, hail caused more property damage than tornadoes or thunderstorms.  Only Tropical Storms/Hurricanes at $12 billion, coastal storms at $1 billion and flooding at $1 billion were more costly than hail to property.

One of the items very susceptible to damage is the HVAC system.  The heat that is removed from the interior of a building must be rejected to the environment.   As such the HVAC system is placed where it can have unhindered access to outdoor air in order to function properly.  This often results in the unit being placed in a large open space such as a rooftop, making it susceptible to damage such as hail.  Read More

Author

Chad Jones
Machine guard for blog

Machine Guarding and Risk Assessment

Author

The Occupational Health and Safety Administration (OSHA) “Top 10 for 2018” violations once again have Machine Safeguarding earning a position on the list. Machine safeguarding was the 9th most cited standard as noted in the list below:

  1. Fall protection, construction (29 CFR 1926.501)
  2. Hazard communication standard, general industry (29 CFR 1910.1200)
  3. Scaffolding, general requirements, construction (29 CFR 1926.451)
  4. Respiratory protection, general industry (29 CFR 1910.134)
  5. Control of hazardous energy (lockout/tagout), general industry (29 CFR 1910.147)
  6. Ladders, construction (29 CFR 1926.1053)]
  7. Powered industrial trucks, general industry (29 CFR 1910.178)
  8. Fall Protection–Training Requirements (29 CFR 1926.503
  9. Machinery and Machine Guarding, general requirements (29 CFR 1910.212)
  10. Eye and Face Protection (29 CFR 1926.102)

(Source: www.osha.gov/Top_Ten_Standards.html)

Read More

Unguarded Shear point 1 white

Unguarded Shear Point on Force Tester Amputates Worker’s Finger

A worker was injured while testing gas springs similar to the type that hold the hatchback of an SUV open. The hazard that injured the worker was an unguarded shear point. The tester contained a mounting plate that was raised and lowered by a pneumatic cylinder.

The pneumatic cylinder lowered the mounting plate while the worker’s fingers were in the hazardous, unguarded shear point. Read More

Orange mini excavator

Case Study: Fatality Servicing Unsupported Excavator Boom

A mini-excavator at a job site developed a leak at a hydraulic fitting at the base of the cylinder that raises and lowers the boom. A subcontractor foreman at the site raised the boom to search for the leak. The foreman found and attempted to tighten the leaking fitting. When he did, the fitting separated from the base of the cylinder, releasing the hydraulic pressure that held the boom aloft. The boom fell and the bucket struck a nearby superintendent for the general contractor.

Read More

Gas Appliance testing lab

Testing As Part of Gas Appliance Incident Investigation

Author

Equipment and appliances supplied with fuel gases like natural gas, propane and butane are a common and convenient part of most of our lives.  Such devices as gas grills and ranges, ovens, furnaces, space heaters and water heaters usually perform without incident.  However, when they malfunction the potential for incidents such as fires and explosions, carbon monoxide (CO) poisoning and burn injuries may occur. These incidents may be due to design and manufacturing defects in the product, or improper installation or operation of the device.

Read More

box bailer

Defective Vertical Baler Causes Serious Crush Injury to Operator’s Arm

I recently worked on an interesting case involving a box baler. An employee of a butcher shop put some empty cardboard boxes in a vertical box baler and pushed the control switch to compact the boxes. After the 30 by 60 inch platen weighing 851 pounds returned to its raised position, the employee reached into the open space above the bottom door on the baler and began to clear cardboard from the bale tie slots in the bottom of the raised platen. Suddenly, and without warning, the steel pin attaching the platen to the raised hydraulic cylinder rod failed. The heavy steel platen fell and crushed his arm which was outstretched over the baler door into the compaction space.

Read More

nail gun

Should I Trust My Nail Gun?

Author

Can you imagine framing a house with the tools of our forefathers, using hand saws and hammers, rather than power saws and pneumatic nail guns? Power tools have made the job much easier and faster, that even the amateur is well equipped for this kind of work. Read More

Figure 1:  A view of the blower machinery.

Improper Design Leads to Fatigue Failure In Blower Shaft

Author

A blower used to exhaust air from an industrial process stopped functioning when the blower wheel drive shaft fractured.  The process, and thereby most of the plant, had to operate at a reduced volume until the blower wheel could be replaced.  The blower wheel had been installed during a shutdown a week before the incident.  The blower wheel was a spare installed when the existing blower wheel was sent for scheduled remanufacturing. Read More

stock-picker-forklift

Evolution of Narrow-Aisle Stock Picker Forklifts

Author

As the cost of warehousing has increased over time, material handling equipment has evolved to allow higher density storage capacities. Narrow aisle and order picker forklifts are among the innovations that have evolved over the past 50 years to accommodate this trend. Read More

Figure 2: A view of some of the undersize anchors used to secure the capstan winch. The anchors at the upper right failed by pulling out of the concrete slab. The one at the lower left failed by bending and pulling out.

Injury Involving a Capstan Winch

A capstan winch uses a mechanically powered rotating cylinder, called a capstan, to apply pulling force through a rope. When the rope is looped around the rotating capstan and tightened, friction between the rope and capstan allows the winch to apply force to pull a load. A typical capstan winch is shown in Figure 1 below. Read More
